EVCO S.p.A. EV3 CHIL & EVD CHIL | Installer manual ver. 1.2 | Code 1443DCHILE124
page 42 of 46
EV3K01 None.
Volt-free contact digital inputs (5 VDC, 1,5mA)
Power supply: none.
Protection: none.
Analogue outputs
EV3 CHIL
2 outputs that can be set up using the configuration parameter for 0-10V, phase
cutting or PWM.
EVD CHIL
EV3K01 none.
Analogue outputs 0-10V (max. 10mA)
Input resistance: 1 KΩ.
Resolution: 0.01 V.
Protection: none.
Phase cutting analogue outputs
Output: 10VDC, max. 10mA
Protection: none.
PWM analogue outputs
Output: 10VDC, max. 10mA
Frequency: 10... 2KHz.
Duty: 5... 95%.
Protection: none.
Digital outputs
EV3 CHIL
Up to 6 outputs:
- 4 with SPST electro-mechanical relay, 2A res. @ 250 VAC
- 1 with triac 200mA res. @ 250VAC at 25°C (77°F)
- 1 with triac, 2A res. @ 250VAC at 25°C (77°F).
EVD CHIL
Up to 5 outputs:
- 2 with SPST electro-mechanical relay, 3A res. @ 250VAC
- 1 with SPST electro-mechanical relay, 8A res. @ 250VAC
- 1 with SPST electro-mechanical relay, 12A res. @ 250VAC
- 1 with open collector, 12VDC, max. 40mA.
EV3K01 None.
Type 1 or Type 2 Actions
EV3 CHIL
Type 1.
EVD CHIL
EV3K01 Not applicable.
