EVCO S.p.A. EV3 CHIL & EVD CHIL | Installer manual ver. 1.2 | Code 1443DCHILE124
page 38 of 46
10 TECHNICAL SPECIFICATIONS
10.1 Technical specifications
Purpose of the control
device
EV3 CHIL
Function controller.
EVD CHIL
EV3K01
Construction of the
control device
EV3 CHIL
Built-in electronic device.
EVD CHIL
EV3K01
Container
EV3 CHIL Black, self-extinguishing.
EVD CHIL Grey, self-extinguishing.
EV3K01 Black, self-extinguishing.
Category of heat and fire
resistance
EV3 CHIL
D.
EVD CHIL
EV3K01
Measurements
EV3 CHIL 75.0 x 33.0 x 59.0mm (2.952 x 1.299 x 2.322 in; L x H x D).
EVD CHIL 71.0 x 110.0 x 60.0mm (2.795 x 4.330 x 2.362 in; L x H x D); 4 DIN modules.
EV3K01 75.0 x 33.0 x 39.5mm (2.952 x 1.299 x 1.555 in; L x H x D).
Mounting methods for the
control device
EV3 CHIL To be fitted to a panel, snap-in brackets provided.
EVD CHIL
On a DIN rail 35.0 x 7.5 mm (1.377 x 0.295 in) or 35.0 x 15.0mm (1.377 x
0.590 in), in a control panel.
EV3K01 To be fitted to a panel, snap-in brackets provided.
Degree of front
protection
EV3 CHIL IP65.
EVD CHIL IP40.
EV3K01 IP65.
