6 OPERATION
6.1 Switch on and resynchronization
At switch-on and after a resynchronization, the fundamental parameters for moving the motor are acquired.
The parameters of pressure and temperature units of measure are loaded at switch-on, and, if necessary, is performed
the conversion of all the parameters of pressure and temperature.
The parameters that are loaded only during the initialization phase, and therefore require a reset to be loaded, are
referred to as manufacturer parameters (Manufacturer menu) and can be modified only in the stand-by state.
To select the desired valve, it is necessary to set the correct value in Valve selection (parameter Pi07).
Setting this parameter to a value of 0 (generic valve) means setting the parameters Pr50 and parameter Pr55 is
required, with which it is possible to specify the value of each valve parameter.
With function “Copy selected to generic valve” it is possible to copy the default values of the selected valve into the
ones of the generic valve, in order to use them as reference for possible modifications.
If a predefined valve is selected (parameter Pi07 > 0), all relevant parameters specific to that valve are loaded
automatically from the flash memory, according to the table below:
Pi07
Valve name
Minimum regulation
steps [step]
Maximum
regulation
steps [step]
Overdriving
steps [step]
Stepping
rate [step/s]
Operating phase
current [mA]
Holding phase
current [mA]
Recommended Step
Mode
0 Generic valve 0 0 0 0 0 0 Full step 2ph
1 Sporlan CO2 0 2500 3125 400 275 0 Full step 2ph
2 Sporlan SER AA
Sporlan SER A
Sporlan SER B
Sporlan SER C
Sporlan SER D
0 2500 3500 400 120 0 Full step 2ph
3 Sporlan SERI F
Sporlan SERI G
Sporlan SERI J
Sporlan SERI K
Sporlan SERI L
0 2500 3500 400 120 0 Full step 2ph
4 Sporlan SER 1.5 to 20 0 1596 3500 400 160 0 Full step 2ph
5 Sporlan SEI 0.5 to11 0 1596 3500 400 160 0 Full step 2ph
6 Sporlan SEI 30 0 3193 6500 400 160 0 Full step 2ph
7 Sporlan SEI 50 0 6386 7500 400 160 0 Full step 2ph
8 Sporlan SEH 100 0 6386 7500 400 160 0 Full step 2ph
9 Sporlan SEHI 175
Sporlan SEHI 400
0 6386 6500 400 160 0 Full step 2ph
10 Sporlan SDR-3 0 3193 3512 200 160 0 Full step 2ph
11 Sporlan SDR-4 0 6386 7025 200 160 0 Full step 2ph
12 Sporlan ESX unipolar 24 224 300 40 260 0 Full step 2ph
13 Sporlan EDEV B unipolar
Sporlan EDEV C unipolar
0 800 1250 200 120 0 Half step
20 Castel 261 0 415 515 35 200 0 Full step 2ph
21 Castel 262
Castel 263
0 195 255 25 200 50 Full step 2ph
22 Castel 264 0 985 1135 70 560 50 Full step 2ph
30 Alco EXM unipolar
Alco EXL unipolar
16 250 350 45 130 0 Half step
31 Alco EX4
Alco EX5
Alco EX6
0 750 1000 500 500 100 Full step 2ph
32 Alco EX7 0 1600 2000 500 750 250 Full step 2ph
33 Alco EX8 0 2600 3250 500 800 500 Full step 2ph
40 Danfoss ETS 12C
Danfoss ETS 24C
Danfoss ETS 25C
Danfoss ETS 50C
Danfoss ETS 100C
0 600 628 240 800 0 Full step 2ph
41 Danfoss ETS 12.5
Danfoss ETS 25
Danfoss ETS 50
0 2625 3150 300 100 75 Full step 2ph
42 Danfoss ETS 100 0 3530 4250 300 100 75 Full step 2ph
43 Danfoss ETS 250
Danfoss ETS 400
0 3810 4550 300 100 75 Full step 2ph
44 Danfoss ETS 6 unipolar 0 240 260 25 260 0 Half step
