EVCO S.p.A. EVDRIVE03 | User manual ver. 3.7 | Code 144EPDE374
Page 33 of 76
To quit the procedure operate as follows:
11. Press and release button ESC over and over again: possible modifications will not be saved.
7.5 Connecting the device through the set-up software
system Parameters Manager
The following procedure shows how to connect the device to the set-up software system Parameters Manager.
For further information please consult the application manual of Parameters Manager.
Operate as follows:
1. To connect the device to the set-up software system Parameters Manager through the programming port, make
sure to have the programming kit EVIF20TUXI; to connect the device to the set-up software system Parameters
Manager through the RS-485 port, make sure to have the non optoisolated RS-485/USB serial interface
EVIF20SUXI.
2. Switch off the power supply of the device.
3. Connect the kit (or the interface) to the Personal Computer; look at paragraph 10.2.4 (or 10.3.4) “Connection
to the Personal Computer”.
4. Switch on the power supply of the device.
5. Operate as related in the User manual of Parameters Manager.
7.6 Main menu
The following procedures show how to gain access to the main menu.
The main menu provides information on the project, on the status of the inputs, allows to set the level’s passwords,
etc.
To gain access to the procedure operate as follows:
1. Make sure the power supply is switched on.
2.1 If you are using a built-in version, keep pressed 2 s buttons UP and DOWN: the display will show the following
menu.
2.2 If you are using a blind version through a remote user interface (for example Vgraph), keep pressed 2 s
buttons ESC and RIGHT: the display will show the following menu.
EVDrive03
Info
Parameters
Networks
...
Diagnostic
Set Password
Debug variables
The access to some submenus is protected by password.
To gain access to a not protected submenu operate as follows:
3. Press and release button UP or button DOWN to select the submenu.
4. Press and release button ENTER.
