11 TECHNICAL DATA
11.1 Technical data
Purpose of the device: electronic expansion valves driver.
Box: self-extinguishing grey.
Size:
71.0 x 128.0 x 60.0 mm (2.795 x 5.039 x 2.362 in; W x H x D);
4 DIN modules.
Size refers to the device with the extractable screw terminal blocks
properly plugged.
Installation:
on DIN rail 35.0 x 7.5 mm (1.377 x 0.295 in) or 35.0 x 15.0 mm
(1.377 x 0.590 in).
Index of protection: IP20; IP40 the front.
Connections:
EPD4BX3 EPD4BC3 EPD4BF3 EPD4DF3
male
extractable
screw terminal
blocks with
pitch 5.0 mm
(0.196 in;
power supply
and outputs;
with pitch 3.5
mm for analog
inputs and free
of voltage
digital inputs)
for conductors
up to 2.5 mm²
(0.0038 in²), 6
poles female
RJ11
telephone
connector
(setting and
programming
port).
male
extractable
screw terminal
blocks with
pitch 5.0 mm
(0.196 in;
power supply,
high voltage
digital inputs,
outputs, CAN
port; with
pitch 3.5 mm
for analog
inputs and free
of voltage
digital inputs)
for conductors
up to 2.5 mm²
(0.0038 in²), 6
poles female
RJ11
telephone
connector
(setting and
programming
port).
male extractable screw terminal
blocks with pitch 5.0 mm
(0.196 in; power supply, high
voltage digital inputs, outputs,
CAN port and RS-485 port; with
pitch 3.5 mm for analog inputs
and free of voltage digital
inputs) for conductors up to 2.5
mm² (0.0038 in²), 6 poles
female RJ11 telephone
connector (setting and
programming port).
