31
Important
Always secure the booster seat with the lower anchor
connectors or vehicle seat belt when not occupied. An
unsecured booster seat can fly into and injure other
occupants in the event of a crash.
Using as a Booster Seat
Child Requirements
• Weight: 18.1-45.3 kg (40-100 lbs)
• Height: 110-145 cm (43.3 to 57 in)
and tops of the child’s ears are at or
below the top of the child restraint
headrest
• Age: At least 5 years old
IMPORTANT: Once your child exceeds any of the
size requirements above for belt-positioning use,
you MUST discontinue use of this seat. Your child
may be ready for use of the vehicle belt system only
at this time.
The shoulder belt MUST
cross midway between
child’s shoulder and neck.
The lap belt is stretched
low and snug across the
child’s hips.
The shoulder belt MUST be routed
properly. See Page 38.
The lap and shoulder belts MUST pass
beneath the lower belt guide and fasten into
the buckle (Canadian models only).
Using as a Booster Seat
