6.Maintenance and Cleaning
The filter prevents larger remnants of food or other objects from getting into the pump.
This residue can occasionally clog up the filters.
The filter system consists of a coarse filter (flat main filter)
and a microfilter (Fine filter).
Food and soil particles trapped in this filter are pulverized by a
special jet on the lower spray arm and washed down to drain.
Larger items, such as pieces of bones or glass, that could block
the drain are trapped in the coarse filter. To remove the items
caught by the filter, gently squeeze the tabs on the top of this
filter and lift out.
This filter holds soil and food residues in the sump area and
prevents it from being redeposit on the dishes during wash cycle.
Main filter
1
Coarse filter
2
Fine filter
3
2
3
1
Filtering System
Filter assembly
The filters efficiently
For best performance and results, the filters must be cleaned regularly. For this reason, it is a good idea to
remove the larger food particles trapped in the filters after each wash cycle by rinsing the semicircular filter and
cup under running water. To remove the filter device, pull the cup handle in the upward direction.
remove food particles from the wash water, allowing it to be recycled during the cycle.
WARNING!
The dishwasher must never be used without the filters.
Improper replacement of the filter may reduce the performance level of the appliance
and damage dishes and utensils.
n
n
1
2
Open
Step 1:£Turn the filter in anti-clockwise direction,
then lift it up.
Step 2:£Lift the Main filter up
3
Step 3: Lift the Fine filter up
NOTE:
11
The filter system is replaced by following the same sequence in reverse.
