BARBECUE ASSEMBLY: ADDING COOKING PLATES
D
NOTE: THE HOOD AND BUILT-IN STRUCTURE ARE NOT SHOWN FOR CLARITY.
7
8
9
1. WITH THE BARBECUE & HOOD ASSEMBLY IN PLACE, THE SUPPLIED PLATES CAN BE FITTED. PLACE THE
VAPOURISER (DIMPLES UP) IN PLACE OVER THE RHS 2 BURNERS. PLACE THE GRILL PLATE OVER THE
VAPOURISER ON THE RHS.PLACE THE SOLID PLATE OVER THE LHS 2 BURNERS.
2. SLIDE THE LINED FAT TRAY FULLY UNDER THE BURNERS (FROM UNDER THE CONTROL PANEL).
3. THE BARBECUE IS NOW READY FOR OPERATION.
