11 Appendix
94/ 106 Cameo User Manual | © Eversys AG
11.3.3 e'2 / e'2m
600 (23.6)
70 (2.7)
125 (4.92)
556 (21.89)
713 (28.07)
65 (2.56)
165 (6.49)
840 (33)
560 (22)
157 (6.45)
Dimensions: mm (inch)
e'2 / e'2m
e'2 e'2m e'2m cup heater e'2m fridge
w/h/d mm
w/h/d (inch)
560/713/600
(22 / 27.9 / 23.6)
560/713/600
(22 / 27.9 / 23.6)
840/713/600
(33 / 27.9 / 23.6)
840/713/600
(33 / 27.9 / 23.6)
weight kg
weight (lb)
83
183
87
191
112
246
117
257
e'2 / e'2m / cup heater
e'2m / fridge
&DSDFLW\
Coffee 175 Espresso / hour at 23s extraction time
2 Espresso at the same time
Steam Manual steam, continuous steam supply
Autosteam, temperature controlled
Everfoam, fully automatic frothing (option)
Hot Water 150 hot water units / hour, 200ml (6.8 oz US)
Milk system 175 Cappuccino / hour
7HFKQLFDOGDWD
Brew chamber 1 x up to 24g
Grinding 2 x drive ceramic grinder disk
User Interface 1 x 8" color touch screen
Bean hoppers 2 x 1.5kg (3.3 lb)
Coffee spout hgt 65mm to165mm (2.55 to 6.49 inch)
Interface USB, SD-Card, Ethernet, Serial, RS-232, CCI
Standby mode less than 2W
Steam boiler size e'2: 8 litre (2.11 gal US)
e'2m: 5.6 litre (1.48 gal US)
Coffee boiler size 1.5 litre (0.39 gal US)
Lighting concept Front panel full color LED
3RZHUUHTXLUHPHQW
Single-phase
1/N/PE, 220-240V~, 50/60Hz, 25A, 5.8k
Two-phases
(US, JP)
2/PE, 200-210V~, 50/60Hz, 30A, 4.9kW
Three-phases
3/N/PE, 380-420V~, 50/60Hz, 15A, 9.6k
Tree-phases
(Triangle) 3(ǻ9a+]$N:
:DWHU&RQQHFWLRQ
Water G3/8" female, 2.5 - 4 bar
Water hose 2 m length (78.7 inch)
Drain Self priming (see drawing rear side)
Water quality Total hardness: 5 - 8°dGH (89-142 ppm)
Carbonate hardness: max. 6°dKH (107 ppm)
pH value: ideal 7.0 - 7.2
)ULGJH
4 litre container (1.05 gal US)
Milk tube length max 1.5m (59 inch)
