7700 MultiFrame Manual
7700FC VistaLINK® Frame Controller
7700FC-22 Revision 1.4.7
4. At the prompt, type “boot<space>upgrade”<Enter>.The following information is displayed on the
screen:
EVERTZ 7700FC BOOT MONITOR.
MON8240 1.1 BUILD 4.
COPYRIGHT 2000 EVERTZ MICROSYSTEMS LTD. ALL RIGHTS RESERVED.
UPGRADE JUMPER PRESENT
UPLOAD MAIN PROGRAM
BB0BB0
UPLOAD CANCELLED
ENTERING COMMAND LOOP
> upgrade -u
UPLOAD UPGRADE PROGRAM
UPLOAD OKAY
> boot upgrade
RUNNING 14B4
7700FC BOOT SOFTWARE
0.00 build 10 (2001 Nov 27 11:25:08)
total memory = 33554432 bytes
available memory = 32133120 bytes
PCI: 33 MHz, bus: 100 MHz, core: 200 MHz, tb: 25 MHz
PCI: 30000 ps, bus: 10000 ps, core: 5000 ps, tb: 40000 ps
ip address: 192.168.1.187, netmask: 255.255.255.0, gateway: 192.168.1.1
The IP address, netmask and gateway information is extracted from the 7700FC configuration information
as entered in the previous section. This IP address should be recorded as it is used for 7700FC Frame
Controller image upgrading, as per the next instruction..
"
If the IP address, netmask and gateway are set to 0.0.0.0, this indicates that the
7700FC card is operating in DHCP mode. You will have to turn off DHCP mode and
enter static IP address and netmask using the procedure shown in section 6.2.1.
5. Using the “Run…” command in the “Start” menu, or opening a Command Prompt (MS-DOS) window,
type “ftp 192.168.1.187<Enter>” (or similar IP address from the previous instruction, as
displayed). This will open an MS-DOS FTP window. Note that the PC, used for entering commands
and storing the downloaded image file, and 7700FC must be configured to operate on the same LAN.
For example the IP address of the PC and Frame Controller should be on 192.168.1.x with “x” being a
unique address identifier for the PC and the 7700FC Frame Controller
• Do not enter a name for “User” when prompted (leave the field blank). Press <Enter>.
• Do not enter a name for “Password” when prompted (leave the field blank). Press <Enter>.
6. At the “ftp>” prompt, type:
put<space>“[dir]\XvY_Z_7700FC.bin”<space>image<Enter>
Add the full path name (directory location) of the downloaded 7700FC Image file in place of [dir] in the
above entry. If there are spaces in the path name they must be surrounded by quotations. Note that “X”,
“Y” and “Z” are FC image release version numbers as identified in the downloaded file name. The file will
take approximately 5 to 10 minutes to upload.
