evertz 7700FC - Upgrading the 7700 FC Frame Controller

7700 MultiFrame Manual
7700FC VistaLINK® Frame Controller
Revision 1.4.7 7700FC-21
EVERTZ 7700FC BOOT MONITOR.
MON8240 1.1 BUILD 4.
COPYRIGHT 2000 EVERTZ MICROSYSTEMS LTD. ALL RIGHTS RESERVED.
UPGRADE JUMPER PRESENT
UPLOAD MAIN PROGRAM
BB0BB0
UPLOAD OKAY
RUNNING 6C0000
>> NetBSD/evertz 7700FC Boot, Revision 2.0 Build 12
>> (rjalali@brain, Fri Nov 5 10:33:15 EST 2004) >
7.3.7. Upgrading the 7700FC Frame Controller
1. Pull the card out of the slot and then reinsert it back into the frame. After the card powers up and the
“Upload Main Program” message is displayed, press <Ctrl-x> five (5) times. This action temporarily
postpones the “upgrade“ procedure. The following information is displayed on the screen:
EVERTZ 7700FC BOOT MONITOR.
MON8240 1.1 BUILD 4.
COPYRIGHT 2000 EVERTZ MICROSYSTEMS LTD. ALL RIGHTS RESERVED.
UPGRADE JUMPER PRESENT
UPLOAD MAIN PROGRAM
UPLOAD CANCELLED
ENTERING COMMAND LOOP
2. At the prompt “>”, type “upgrade<space>–u<Enter>” The following is displayed on the screen:
EVERTZ 7700FC BOOT MONITOR.
MON8240 1.1 BUILD 4.
COPYRIGHT 2000 EVERTZ MICROSYSTEMS LTD. ALL RIGHTS RESERVED.
UPGRADE JUMPER PRESENT
UPLOAD MAIN PROGRAM
BB0BB0
UPLOAD CANCELLED
ENTERING COMMAND LOOP
> upgrade –u
UPLOAD UPGRADE PROGRAM
3. Using the procedure outlined in section 7.3.6 send the Upgrade program to the 7700FC
(upgrade_0v0_24.bin - that was downloaded in section 7.3.1). Upon completion of this step, the
following information will be displayed on the screen:
EVERTZ 7700FC BOOT MONITOR.
MON8240 1.1 BUILD 4.
COPYRIGHT 2000 EVERTZ MICROSYSTEMS LTD. ALL RIGHTS RESERVED.
UPGRADE JUMPER PRESENT
UPLOAD MAIN PROGRAM
BB0BB0
UPLOAD CANCELLED
ENTERING COMMAND LOOP
> upgrade –u
UPLOAD UPGRADE PROGRAM

UPLOAD OKAY
>
