15
Component Identification – Manual Tilt Models
Item Description Item Description
8 Fuel Connector 13 Oil Fill Cap
9 Battery Cable
(electric start models only) 14 Oil Tank
10 Air Silencer 15 Spark Plugs
11 Fuse 16 EMM (Engine Management Module)
12 Spare Fuse 17 Rewind Starter / Flywheel Guard
17
16
15
008495
Starboard
8
10
11
13
14
9
008494
Port
12
