Adjusting the card thickness
The printer is equipped with a manual card thickness adjustment system, which can be reached at the printer feeder.
The printer accepts cards between 0.51 mm and 1.25 mm thick (20 to 50 mil). The factory setting for card thickness is 0.76 mm.
To change the exit setting, launch the EPS driver on Windows or CUPS driver on Macintosh and open the Feeder/Hopper tab.
It is also possible to change the setting for the ejection of defective cards through the Feeder/Hopper tab.
NOTE
KC PRIME
18
Removing printed cards
Once the print cycle is complete, the printed and/or encoded card is issued by default through the slot on the rear (R) side of the printer (with or
without bezel).
