Evolution Dog Wash Owners/Operators Manual Page 47
8.0 EVOLUTION Parts Identification and Location
The EVOLUTION Dog Wash Company strives to provide the best products available to us at time of
manufacture, but due to design changes by EVOLUTION or providing manufacture the components
provided in your EVOLUTION may be slightly different than shown here but will function in the same or
similar manner.
8.1 Outside The EVOLUTION
Blower Hose
Wash Gun and Gun Holder
Meter
Door Swing Handle and Locking Point
Blower Nozzle and Bracket
Door Locking Lugs(2)
Wash Compartment Latch
Front
Removable Access Panel
Wash Compartment Door
Drain Basket
Electrical Access Hole
Back
Water Connection Point
Removable Access Panel
ADA Latch Release
