Evolution Dog Wash Owners/Operators Manual Page 48
8.2 Inside The EVOLUTION
Water Manifold
Water Manifold
Injector Manifold
Press Regulator
Shut Off Valve
Thermostatic Valve
Gauge
Manifold
Solenoid Valve
Product Injector
Optional Water Heater
Compartment
Main Control Panel
Blower
Vent Louvers
Incoming Water
Product Pumps
Door Lock
Breaker Panel
Door
Door Closure
Startup Product
Operator Switch
Note Acceptor
Coin/Token Acceptor
Locking Coin Box
Optional Credit Card Reader
