Evolution Dog Wash Owners/Operators Manual Page 9
The PLC + model comes with a Human Machine Interface (HMI) computer that has
many features to assist in data sampling and data logging. Data is collected and
stored as multiple files for later retrieval in the internal memory
of the HMI. Data can be retrieve via an internet
connection or as needed from the touch panel displayed
of the HMI located inside the cabinet.
2.4 Specifications
Aircraft Grade 304 B Stainless Steel Construction
Self-Contained Cabinet for Interior or Exterior Operations
Triple Redundant Exterior Locking
Key Secured Cabinet housing all electronics, products, and collected money
Water Usage – 1.7>2.5 GPM (8-13G per wash)
Standard wash charge is programable
Wash Cycle Cost is approx. $0.95 - $1.20 (estimated for a 10 minute wash cycle)
2.5 Requirements
Water (Required)
Cold Water Line 20-60 PSI/2.0 GPM
Hot Water
1
Line 20-60 PSI/2.0 GPM
2” Sanitary Sewer Waste (Required)
120 Volts AC 30 Amps Hardwired Dedicated Circuit (Required)
2
2.6 Dimensions and Weights
Length 79.5” / Height 74.6” / Depth 27.7”
Weight 750 Pounds
3
Crated Weight 1000 – 1050 lbs. approx.
1
Hot Water Supply Line is optional. If a hot water supply is not available, the Internal Water Heater option must
be selected. An additional 120 Volt AC/ 20 Amp circuit is required to drive the water heater.
2
Main power to the unit should be on a dedicated circuit, not shared with other devices or equipment.
3
Add 65 lbs. with optional water heater
