TURNING SIGNAL LIGHTS CONTROL
OPER AT ION AND CONTROLS OPER AT ION AND CONTROLS
HORN CONTROL
FRONT HEADLIGHT CONTROL
The headlight and turning signal switch is located on the steering column under the steering
wheel. The switch lever is located on the driver side.
Pushing the lever up will activate the right
turning lights, including front and rear
turning lights
.
Press the horn button (on the end of switch
lever) will activate the horn.
Pulling the lever down will activate left
turning lights, including front and rear
turninglights..
TURNING SIGNAL LIGHTS CONTROL
Pushing the lever down will activate the
front headlights.
COMBINATION SWITCH CONTROL MOTOR BRAKE RELEASE SWITCH (Electrical)
(Optional)--Old Type (Optional)
The motor brake releasing switch is located under
the front seat cushion, on the passenger side.
You can lift up the front seat cushion and find the
switch. See image on the right.
The switch is used for releasing the motor brake
manually when the vehicle needs to be towed by
trailer or pushed by people.
Press down the switch to release the motor brake.
Press up the switch to activate the motor brake.
Turn on the key switch before operating the switch
to engage the function.
MOTOR BRAKE RELEASE SCREWS (Mechanical)
--Old Type (Optional)
MOTOR BRAKE RELEASE LEVER (Mechanical)
--New Type(Optional)
Use the Allen wrench (M5) to tighten 2pc small
hexagonal socket head screws located on the
left end face of AC motor, then it will disable the
Electromagnetic Brake (EM-Brake) function,
and release EM-brake disc. Then the vehicles
can be towed or pushed freely.
Press this
plate
For new type motor brake releasing lever, to
to release the motor brake, press the plate on
the motor brake mechanism and then pull the
releasing lever to the right side on the image
to release the motor brake, then the vehicle
can be pushed or towed freely.
NOTICE
Allen key
