MACHINE OVERVIEW
A. BLADE GUARD
B. BLADE NOT VISIBLE
C. RIVING KNIFE
D. RIP FENCE
E. RIP FENCE LOCKING HANDLE
F. PUSH STICK STORAGE
G. SERIAL NUMBER / RATING LABEL
H. TABLE EXTENSION LOCKING LEVER
I. LATCHING PIN
J. BLADE HEIGHT & BEVEL
ADJUSTMENT WHEEL
K. BEVEL LOCKING LEVER
L. ON/OFF SWITCH
M. SLIDING CARRIAGE UNLOCKING PIN
N. SLIDING MITRE FENCE
O. ANTIVIBRATION DEVICE
A
B
J
F
N
D
L
H
C
K
G
O
E
M
I
