Video and Codecs
The codecs modules allow connections for recording and playback of video material.
Each connector on a codec module is connected to the corresponding J connector on the
COD A or COD B module of a V3X board.
See section "V3X Video and Reference Boards" on page 78 for more details on each
connector specific usage according to the different configurations.
The video and codec connector layouts described in this section are available according
to your configuration.
2-Channel Version
4-Channel Version
6-Channel Version
