SMPTE Standards
The following table lists the SMPTE standards supported by your server.
Configuration SMPTE standard
SD SDI ST 259:2008 (525i 59.94Hz; 625i 50Hz)
HD SDI ST 292-1:2011, ST 292:2012
(720p 50 and 59.94Hz; 1080i 50 and 59.94Hz)
Embedded audio HD ST 299-0:2010, ST 299-1:2009
AES/EBU audio ST 272:2004
LTC ST 12-1:2008, ST12-2:2008
D-VITC ST 266:2012
Ancillary TC in HD RP 188
Vertical Ancillary Data ST 334:2000
VC-3 ST 2019-1:2008
IMX D-10 ST 356:2001
Dual Link 1.5 Gb/s ST 372:2011
Mapping of Audio Metadata into
Vertical Ancillary data
ST 2020-2:2008, ST 2020-3:2008
3G SDI ST 424:2006
3G SDI – Data mapping ST 425-B:2008
4.2. Audio Specifications
Audio Analog and Digital Configurations
4U Server
The following optional audio configurations are available:
• Configuration BNC AES/EBU + DA-15 Analog :
◦ 16 input and 16 output (8 pairs + 8 pairs) AES/EBU or Dolby E unbalanced on 16
BNC connectors
◦ 8 input and 8 output analog balanced channels on 4 DA-15 connectors
• Configuration DA-15 AES/EBU + DA-15 Analog:
◦ 16 input and 16 output (8 pairs + 8 pairs) AES/EBU or Dolby E on 4 DA-15
connectors
◦ 8 input and 8 output analog balanced channels on 4 DA-15 connectors
HARDWARE TECHNICAL REFERENCE MANUAL XT3 Server 11.02
4. Software Specifications 15
