6.2.6. Channel Assignment
Server with Three Codec Boards
The following table shows how the channels (play or record channels) are assigned to the
codec boards and connectors:
Codec Board Codec Connector Channel Number
Lower codec board (slot 2) COD A CAM F or PGM 1
Lower codec board (slot 2) COD B CAM E or PGM 2
Middle codec board (slot 3) COD A CAM D or PGM 3
Middle codec board (slot 3) COD B CAM C or PGM 4
Upper codec board (slot 4) COD A CAM B or PGM 5
Upper codec board (slot 4) COD B CAM A or PGM 6
Server with Two Codec Boards
The following table shows how the channels (play or record channels) are assigned to the
codec boards and connectors:
Codec Board Codec Connector Channel Number
Lower codec board (slot 2) COD A CAM D or PGM 1
Lower codec board (slot 2) COD B CAM C or PGM 2
Middle codec board (slot 3) COD A CAM B or PGM 3
Middle codec board (slot 3) COD B CAM A or PGM 4
Server with a Single Codec Board
The following table shows how the channels (play or record channels) are assigned to the
codec board and connectors:
Codec Board Codec Connector Channel Number
Lower codec board (slot 2) COD A CAM B or PGM 1
Lower codec board (slot 2) COD B CAM A or PGM 2
HARDWARE TECHNICAL REFERENCE MANUAL XT3 Server 11.02
6. Boards Description 85
