6.5.2. External RAID Array SAS-HDX
The SAS-HDX is a 2U external disk storage containing up to 24 hot-swappable SAS
disks, with a minimum of 5 disks. External storage can be used with or without internal
storage.
It is connected to the server via a dedicated SAS cable on the rear panel of the server,
provided that the X-ESAS connection module has been placed inside the server.
Necessary equipment:
• Server with SAS-HDX connector on the rear panel.
• Multicam version 10.05 or higher
• SAS-HDX external disk storage
