EVS XT-3 Technical Reference

Cable type @ 1485 Mbps
RG59 45m / 148ft
RG6 90m / 484ft
RG11 120m / 393ft
Super HiQ 150m / 492ft
Fiber 80km (*)
(*) 80km/200km is the total length of the return path, i.e. the actual distances between
the 2 servers connected via the fiber link is half of this value, i.e. 40 km @ 1485 Mbps.
Note
When reclockers are used, the total delay induced by these reclockers between
2 active servers on the network may not exceed 15 μs.
5.6.4. Starting XNet
1. When all above conditions are fulfilled and the cabling is correct, turn on the "Server"
EVS video server.
2. Make sure the value to Server in the Type field in the SDTI section on the Network
page. Then start Multicam.
3. Turn on all "Master" and "Client" EVS video servers, and make sure the appropriate
value is selected in the Type field in the SDTI section.
4. Start Multicam on all of the Master and Client EVS servers.
They should see the "Server" on the network and they will connect automatically.
Connection takes a few seconds (usually between 2 and 5 sec) for each EVS video
server.
5.6.5. XNet Performances and Troubleshooting
Performances
With the default settings, the following performances can be achieved in normal
conditions:
Material Transfers Distant copy
SD content 10 real-time
transfers
Up to 5 times faster than real-time
(depends on network load)
HD content 3 to 4 real-time
transfers
Up to 2 times faster than real-time
(depends on network load)
SLSM content 3 real-time
transfers
-
58 5. Hardware Installation and Cabling
EVS Broadcast Equipment S.A. Issue 11.02.A July 2013
