EVS XT-3 Technical Reference

Content Transfer Encoding and File Header
It is possible to perform the encoding process in 8-bit or 10-bit and to write a 10-bit file on
selected codecs.
The following table summarizes the proposed configurations:
Codec Encoding File Header
DNxHD 120/145 8-bit 8-bit
DNxHD 185/220 8-bit 8-bit
DNxHD 185x
DNxHD 220x
10-bit 10-bit
ProRes 85 8-bit 10-bit
ProRes 120/145 8-bit 10-bit
ProRes 185/220 8-bit or 10-bit 10-bit
DVCPro HD 8-bit 8-bit
M-JPEG 8-bit 8-bit
MPEG 8-bit 8-bit
AVC-Intra 100 10-bit 10-bit
Note
When encoding in 10-bit, it is not possible to use the graphic functionality: Paint,
Target, Logo Insertion, and internal offside line.
18 4. Software Specifications
EVS Broadcast Equipment S.A. Issue 11.02.A July 2013
