8.5.2 Earthing plates
- An earthing plate is a shot-peened plate mounted on the hull to recreate an earth neutral point on the electrical circuit
of the equipment supplying AC power (generator and AC/DC convertor). The earthing plate earths this equipment.
The earthing plate is not an anode: it must not be allowed to deteriorate.
- If the earthing plate deteriorates, consult a professional immediately to determine the cause. Because it is mounted
across the hull below the waterline, deterioration of the earthing plate puts the boat at risk of sinking.
Outside view
Inside view
Never antifoul over the earthing plates.
