13.5 MAIN PLUMBING EQUIPMENT
13.5.1 Water unit
- The water unit is powered by direct current.
- It supplies all the boat's plumbed-in equipment with fresh water. It is fitted with a pressure switch that activates the flow when the pressure in the water system falls.
- The water unit must only be used with the fresh water supply. All other use (e.g. seawater, bilge water, oil products) must be strictly avoided.
- The water unit is switched on at the electrical panel.
- Make sure that the water unit never runs dry.
- The pressure and capacity of the water unit depend on the temperature of the stored fresh water supply.
Control: Electrical panel Location: Port engine compartment Water tank / water unit supply valve
- When the water unit is powered by the DC
circuit, the switch lights up in red.
- When the ON indicator turns green, the
water unit is operating.
NOTE: A valve allows the
water unit to be isolated from
the tanks for maintenance
operations.
1. Fresh water filter
2. Water unit
Water systems
13
