9.4 DIAGRAM OF LAYOUT
Europe Version
US Version
Reference Designation
1 Regulator valve
2 Gas cylinder
3Drain
4 Gas bottle connection kit
5 Bubble tester kit
6 Rubber washers
7 Ringed PVC sheath
8 Copper gas connection kit
9 Label
10 Gas appliance connection kit
11 Bulkhead fitting
Reference Designation
1 Regulator valve
2 Gas cylinder
3Drain
4 Electromagnetic valve (12V)
5 Bulkhead fitting
6 Wire passage
7 Ringed PVC sheath
8 Solenoid switch
9 Plastic propane pipe
10 Gas appliance connection kit
Liquefied Petroleum Gas (LPG) System
