Excess 11 - Page 32

32
209173 RCD-2
Index A
Mast Performance
Prebend: 130mm (once the mast has been adjusted according to best practice)
Summary table of standing rigging measurements:
Reference Designation Quantity
Diameter (in
mm)
1 Forestay 1 12
2 Upper shroud 2 12
3 Diamond 1 2 10
4 Diamond 2 2 10
5 Martingale 1 1 8
6 Martingale 2 1 8
Cable Load (min) Load (max)
Shrouds 2 160kg 2 400kg
Diamonds 1 520kg 1 760kg
Martingale 960kg 1 080kg
Rigging and sails
