Main drainage system
Electric bilge pumps
- The bilge pumps are powered by DC.
- The switch for the electric bilge pump is located on the switch panel (Ref 4).
- The electric bilge pump must only be used to discharge stagnant water at the bottom of the bilge. It must not be used to pump out any oil-based products (petrol, oil) or
inflammable liquids.
Location of the electric bilge pumps: Ref 3
Electric bilge pump drain valve
Location: Port & starboard passageway
NOTE: The valve must be opened before starting
the pump.
Starboard electric bilge pump Port electric bilge pump
- Pressing the switch once activates the "automatic" mode of the bilge pump: The
pictogram lights up red.
- Pressing the switch twice activates the "forced run" mode of the bilge pump: The
indicator light ON turns on (bottom right).
- When the indicator light on the bottom left lights up, the bilge pump is in operation.
