5. Computer and Adjustable Levelers Installation
Connect the Sensor Wire (31) to the wire that comes from the Computer (32). Place the
Computer (32) onto the plate on the Main Frame (1) then slide it down to lock in position.
Attach two M8x45 Adjustable Levelers (67) onto the Main Frame (1) with M8 Nuts (68).
67
68
68
1
32
31
