Operation

ToadjusttheFRSbafes:

1.Stopengine,waitforallmovingpartstostopand

removekey.Engageparkingbrake.

2.Removehairpinsandclevispinsfrombothsides

ofthePTOguard(seeFigure5).Foldguard

forward.

3.LoosennylocnutsontherearstudsoftheFRS

bafes.

Figure10

1.PTOguardremovedfor

clarity

2.Loosennylocnuts

4.RaisedeckasstatedinRaisingtheMowerDeck

totheServicePositionsection.

5.Removeboltandwasheratthefrontofeach

oftheFRSbafes.Rotatebafesintodesired

positionandreinstallboltandwasher.

Figure11

1.Bafesshowninclosedposition

2.Bafesshowninopenposition

3.Bolt

4.Washer

5.Bafes

6.LowerdeckperLoweringtheMowerDeckto

theOperatingPositionsection.

7.SnugnylocnutsontherearstudsoftheFRS

bafes.Thesenutsmaybeleftslightlylooseif

frequentbafeadjustmentisanticipated.

8.ReinstallPTOguardusingclevispinsandhair

pinsremovedinstep2.
