Safety
decal135-4573
135-4573
WingDeckModelsOnly
1.Engine–off4.Pushtopofbuttonto
lowerdeck
2.Engine–on
5.Pushbottomofbuttonto
raisedeck
3.Engine–start
decal135-7226
135-7226
1.Accessory—15A4.Enginepowerrelay
2.Power—20A5.Fanrelay
3.Enginestartrelay
decal135-7898
135-7898
WingDeckModelsOnly
1.Wheellugnut—torqueto129N∙m(95ft-lb).
2.Wheelhubnut—torqueto441N∙m(325ft-lb).
3.ReadtheOperator’sManualbeforeperforming
maintenance;checkthetorqueaftertherst100hours
andevery500hoursafter.
decal142-2472
142-2472
1.Accessory—15A3.Enginestartrelay
2.Power—20A4.Enginepowerrelay
g224113
MessageDisplay
AllLZEModels
AllLZS/LZXKawasakiModelsexceptREDEquipped
1.Fuel6.Hourmeter
2.Empty
7.PTO
3.Half
8.Parkingbrake
4.Full9.Neutral
5.Battery
10.Operatorpresence
switch
