Maintenance
MobilHTSGrease(Or
Food-GradeAnti-seize)
X-SeriesOnly
MobilHTSgrease(orfood-gradeanti-seize)isused
inthefollowinglocation:
Betweenthecutterhousingspindlesandbearings.On
96inchdecks,alsogreasetheanti-scalprollerbolts.
Copper-BasedAnti-seize
Copper-basedanti-seizeisusedinthefollowing
location:
OnthreadsofBladeBolts.SeeCheckMower
Bladessection.
DielectricGrease
Dielectricgreaseisusedonallbladetypeelectrical
connectionstopreventcorrosionandlossofcontact.
Dielectricgreaseshouldnotbeappliedtosealed
connectors.
Adjustments
Note:DisengagePTO,shutoffengine,waitfor
allmovingpartstostop,engageparkingbrake,and
removekeybeforeservicing,cleaning,ormakingany
adjustmentstothemachine.
DeckLeveling–
WingDeckModels
LevelingtheCenterandWingDecks
1.Positionthemachineonaatsurface.
2.Shutofftheengine,waitforallmovingpartsto
stop,removethekey,andengagetheparking
brake.
3.Checkthetirepressureindrivetires.Proper
inationpressurefortiresis18psi(124kPa).
Adjustifnecessary.
4.Raisethecenterdeckandfoldthewingsby
pressingdownattherearofthedeckliftrocker
switch.Holdtheswitchdownuntilbothwings
arecompletelyfolded.
5.Insertthecenterheightadjustmentpinintothe4
inches(102mm)cuttingheightlocation.
6.Unlocktheleftandrightwingdeckcamlocks.
7.Removeandretainthewingdeckheightofcut
lynchpins.
g295443
Figure47
1.Unlockcamlock3.Lynchpin
2.Heightofcutpin
67
