Exmark Lazer LZE - Product Overview; Component Identification

ProductOverview
ProductOverview
g031224
Figure3
ModelswithoutaWingDeck
1.RolloverProtection
System(ROPS)
6.Fuelcap
2.Rear,shockassembly
(“C1”,“C2”,&“C3”
Modelsonly)
7.Front,shockassembly
(“C1”,“C2”,&“C3”
Modelsonly)
3.EngineControls(right
console)
8.Heightofcutdecklift
pedal
4.Seatbelt
9.Parkingbrakelever
5.Motioncontrollevers
g292484
Figure4
WingDeckModel
1.RolloverProtection
System(ROPS)
7.Centerdeckheightofcut
2.EngineControls(right
console)
8.Wingdeckheightofcut
3.Seatbelt9.Leftwingdeck
4.Motioncontrollevers
10.Step
5.Fuelcap11.Rightwingdeck
6.Parkingbrake
26
