Exmark LAZER Z E Series User Manual

Operation
Figure9
1.LCDIndicators
2.Lowfuelindicatorlight
3.Fuellevelbardisplay
4.Lowvoltageindicatorlight
5.Hour/Voltagedisplay
Thehourmeterisrecordingwhenthedecimalpoint
isashinginHour/Voltagedisplay.
Hoursaredisplayedwhenthekeyisofforwhenthe
machineisrunning.
Note:Iftheignitionkeyisturnedtothe“ON”
positionforafewsecondsbeforecrankingtheengine,
thebatteryvoltagewilldisplayintheareawherethe
hoursarenormallydisplayed.
Note:TheLCDindicatorsappearwheneachcontrol
meetsthe“safetostart”mode(e.g.theindicator
turnsonwhentheoperatorisintheseat.)
FuelShut-OffValve
Locatedbehindandbelowtheseat.
Thefuelshut-offvalveisusedtoshutoffthefuel
whenthemachinewillnotbeusedforafewdays,
duringtransporttoandfromthejobsite,andwhen
parkedinsideabuilding.
Alignvalvehandlewiththefuellinetoopen.Rotate
90°toclose.
FuelGauge
Locatedontherightconsoleinthemessagedisplay
(seeFigure6andFigure9).
Thefuellevelisshownonabardisplay.Theindicator
lightappearswhenthefuellevelislow(approximately
onegallonremaininginthetank).
DriveWheelReleaseValves
WARNING
Handsmaybecomeentangledintherotating
drivecomponentsbelowtheenginedeck,which
couldresultinseriousinjuryordeath.
Stopengine,removekey,allowallthemoving
partstostopbeforeaccessingthedrivewheel
releasevalves.
WARNING
Theengineandhydraulicdriveunitscanbecome
veryhot.Touchingahotengineorhydraulic
driveunitscancausesevereburns.
Allowtheengineandhydraulicdriveunitsto
coolcompletelybeforeaccessingthedrivewheel
releasevalves.
Locatedonthebackoftheunitizedhydraulicdrive
units,belowtheenginedeck.
Duringnormaloperatingconditions,thedrivewheel
releasevalvesarepositionedhorizontally.Ifthe
machinehastobepushedbyhand,thevalvesmust
beinthe“released”position(seeFigure10).
Figure10
CoolingFanCongurationShown
1.Handlein“released”position
2.Handlein“operating”position
Toreleasethedrivesystem(seeitem1inFigure10),
rotatethehandle1/4turntotheverticalposition
untilithitsagainstthestop.
Toresetthedrivesystem(seeitem2inFigure10),
rotatethehandle1/4turntothehorizontalposition
untilithitsagainstthestop.
29

Exmark LAZER Z E Series Specifications

General

Engine Brand	Kawasaki
Transmission	Hydro-Drive
Deck Construction	Fabricated
Deck Material	10-gauge steel
Turning Radius	Zero
Cutting Width	52, 60, 72 inches
Category	Commercial
Type	Zero-Turn
Engine Type	4-cycle, V-Twin
Engine Options	Kawasaki
Speed	Up to 10 mph forward, 5 mph reverse
Warranty	5-year limited
Horsepower	23.5 - 27
Cutting Height	1.0 - 5.0 inches in 0.25 inch increments
