Operation
Note:Thehandlemustbehorizontalandagainst
thestopforoperation.
DoNottowmachine.
PTOEngagementSwitch
Locatedonrightconsole(seeFigure6orFigure7).
Switchmustbepulledout(up)toengagetheblades.
Switchispushedintodisengagetheblades.
TheLCDindicatorwillappearwhenthePTOswitch
isdisengaged(seeFigure9).
Note:TheEFIREDEquippedUnitshaveaclutch
saver,whichallowsthethrottletoautomatically
reduceengineRPMwhenthePTOswitchis
disengaged.EngaginganddisengagingthePTO
switch,changestheenginethrottlebetweenmowand
transportmode(referencethetableintheThrottle
ControlwithClutchSaver(EFIREDEquipped
Units)section).
LowVoltageIndicator
Locatedontherightconsoleinthemessagedisplay
(seeFigure6andFigure9).
Alowvoltagecondition(lessthan12.3volts)exists
whentheLCDindicatorappearsonthemessage
displaywhiletheengineisrunning.
Iftheignitionkeyisturnedtothe“ON”positionfor
afewsecondsbeforecrankingtheengine,thebattery
voltagewilldisplayintheareawherethehoursare
normallydisplayed.
Note:Theindicatornormallyappearswhenthe
engineisoffandthekeyswitchisturnedtothe
“ON”position.
DeckLiftPedal
Locatedattherightfrontcorneroftheoorpan.
Pushthepedalforwardwithyourfoottoraisethe
cuttingdeck.Allowthepedaltomoverearwardto
lowerthecuttingdecktothecutheightthathasbeen
set.
TransportLock
Locatedontheheightofcutadjustmentplatestothe
rightoftheparkingbrake.
Positioninthetransportlatchingpositionto
automaticallylatchthecuttingdeckwhenraisedto
thetransportposition(seeitem1inFigure11).
Inthenon-latchingposition,thedeckwill
automaticallyreturntothecuttingheightwhenthe
pedalislowered(seeitem3inFigure11).
Figure11
1.Latchingposition3.Non-latchingposition
2.Transportlockcontrol
ElectronicControlUnitMalfunction
Indicator
(EFIUnitsOnly)
Themalfunctionindicatorlight(MIL)isthelight
locatedintherightconsolepanel–therightlight
belowthethrottlecontrol.
Theelectroniccontrolunit(ECU)continuously
monitorsoperationoftheEFIsystem.Ifaproblem
orfaultwithinthesystemisdetected,theMIL
isilluminated.Followthetroubleshootingsteps
outlinedintheKohlerengineoperator’smanualifthe
MILisilluminated.
LowOilPressureWarningLight
(EFIREDEquippedUnitsOnly)
Locatedintherightconsolepanel–themiddlelight
belowthethrottlecontrol.
Iftheengineoilpressuredropsbelowasafelevel,
thislightwillbeilluminatedandtheenginewill
automaticallyreduceRPMandremaininasafe
modeuntilthecorrectiveactionistaken(seethe
Troubleshootingsection).
30

Exmark LAZER Z E Series Specifications

General

Engine Brand	Kawasaki
Transmission	Hydro-Drive
Deck Construction	Fabricated
Deck Material	10-gauge steel
Turning Radius	Zero
Cutting Width	52, 60, 72 inches
Category	Commercial
Type	Zero-Turn
Engine Type	4-cycle, V-Twin
Engine Options	Kawasaki
Speed	Up to 10 mph forward, 5 mph reverse
Warranty	5-year limited
Horsepower	23.5 - 27
Cutting Height	1.0 - 5.0 inches in 0.25 inch increments
