Maintenance
g016165
Figure43
1.Aircleanercover3.Breathervalve
2.Throttlemechanism
3.Securethecoverwithlatches.
ChangeEngineOil
ServiceInterval:Aftertherst5hours
Every100hours/Yearly
(whichevercomesrst)
(Mayneedmoreoften
undersevereconditions.)
1.Stopengine,waitforallmovingpartstostop,and
removekey.Engageparkingbrake.
2.Drainoilwhileengineiswarmfromoperation.
3.Theoildrainhoseislocatedonrighthandside
ofengineattherear.Placepanundermachine
tocatchoil.Removeplugfromendofdrain
hose.Allowoiltodrainandreplaceoildrainplug.
Torqueplugto20-24ft-lb.
4.Replacetheoilltereveryotheroilchange.Clean
aroundoillterandunscrewltertoremove.
Beforereinstallingnewlter,applyathincoating
ofExmark4–CyclePremiumEngineoilonthe
surfaceoftherubberseal.Turnlterclockwise
untilrubbersealcontactsthelteradapterthen
tightenlteranadditional1/2to3/4turn.
5.Cleanaroundoilllcapandremovecap.Fillto
speciedcapacityandreplacecap.
6.UseoilrecommendedintheCheckEngineOil
Levelsection.DoNotoverll.Starttheengine
andcheckforleaks.
7.Wipeupanyspilledoilfromenginedeck
mountingsurfaces.
CheckDeckLiftOilLevel
ServiceInterval:Every50hours
1.Stopengineandwaitforallmovingpartstostop.
Engageparkingbrake.
2.Waituntilthemachinecoolsbeforecheckingthe
deckliftoil.
3.Cleantheareaaroundtheoilllcapandremove
cap.
g299037
Figure44
1.Oillevel
2.Fillcap
4.Theoillevelshouldbeslightlyabovetheinternal
gearpumpinthetank(referenceFigure44).If
needed,addExmarkRubyTran
™
oil.
5.Replacehydraulicreservoircapandtightenuntil
snug.DoNotovertighten.
CheckHydraulicOilLevel
ServiceInterval:Every50hours
62

Exmark LAZER Z Specifications

General

Engine Brand	Kawasaki
Transmission	Hydrostatic
Deck Construction	Fabricated or welded steel
Category	Commercial
Type	Commercial
Speed	10 mph
Turning Radius	Zero-turn
Fuel Capacity	10-15 gallons
Weight	1, 465 lbs
