1.1 Function
Use The exodraft EBC30 is a true PID-based fan speed control used to maintain a constant pressure or
draft in a venting system. It can be used with RSV, RSIF, RSIB, IPVB, BESF, BESB and SFTA models to
control single phase, 120 V AC, motors directly and three-phase, 208-460 V AC, motors indirectly via a
VFD (variable frequency drive) that adjusts the motor speed.
The intended use of the control includes, but is not limited to controlling the:
• combustion air supply system
• draft in mechanical draft system serving individual or multiple heating appliance systems
• damper position in a modulating over-draft system to ensure proper draft is maintained in
individual or multiple heating appliance systems
• duct pressure in dryer venting systems
• duct pressure in ventilation systems.
The EBC30 can simultaneously control an exhaust fan, an intake fan or a draft damper. Any two of
these can be controlled simultaneously or they can be controlled individually.
Use of the control is not restricted to any type of fuel or type of heating appliance, dryer or venting
application.
The unit features “plug-and-play” to automatically monitor all terminals and register components
attached to the control during initial start-up. It comes pre-programmed from the factory, but can be
further programmed in the eld, if needed. The control will allow continuous or intermittent opera-
tion of a mechanical draft fan.
The control has an integrated safety system to assure the heating appliance will shut down in case of
fan failure or control failure. A unique priority operation function will probe the operating conditions
and allow as many appliances as possible to operate without fan assistance, provided the operation
is considered safe by the integrated safety system. The EBC30 has six(6) heating appliance interlock
circuits as standard but can be expanded in multiples of four(4) with the use of an additional relay
board or the ES12, relay control.
The control can be operated with a manual reset function (reset button) or an automatic reset
function. A self- diagnostic panel with LED’s monitors all connection terminals for easy service and
troubleshooting. The EBC30 can also operate in manual mode where the user sets the constant
speed. Provided the integrated safety system is satised, interlocked heating appliances are allowed
to operate. A bearing cycle activation function rotates the fan motor(s) once every 24 hours in case
the fan has not been operating during the previous 24 hour period.
Listings EBC30 is tested and listed to the Standard for Industrial Control Equipment, UL Standard 508 and CSA
C22.2 No. 14-10 as well as UL378, Standard for Draft Equipment.
1.2 Shipping
The EBC30 contains the following:
EBC30 control unit, relay board (optional), pressure transducer (Ashcroft XTP), triac board (optional), silicone tubing, stack
probe and user manual
