6.1 EBC30 Factory settings
Menu Sub-menu function Display Range Default
2 exhaust EXHAUST
21 draft set point SET EXHAUST 3%-95% of sensor range 0.100
22 operation mode OPERATION Continuous/Intermittent Intermittent
23 pre-purge PREPURGE 0
231 time TIME 0-1800 0
232 operation mode SPEED MODE Variable/FIX 20 %-100 % Fix 100 %
24 post-purge POST PURGE
241 time TIME 0-1800 0
242 operation mode SPEED MODE Variable/FIX 20 %-100 % Variable
25 sensor SENSOR
251 min. pressure RANGE MIN -500-+500Pa 0
252 max. pressure RANGE MAX 0-1000 Pa 150 Pa
26 parameters PROPERTIES
261 alarm limit draft ALARM LIMIT 50-80% 64%
262 alarm delay ALARM DELAY 0-120s 15
263 min. voltage SPEED MIN 0-MENU264 15%
264 max. voltage SPEED MAX MENU263-100% 100%
265 xp EXHAUST Xp 0-30 15
266 ti EXHAUST Ti 0-30 8
267 pressure type PRESSURE MOD (+) or (-) Negative
3 intake INTAKE
31 intake set point SET INTAKE 3%-95% of sensor range 0.016
32 operation mode OPERATION Continuous/Intermittent Intermittent
33 pre-purge PREPURGE
331 time TIME 0-1800 0
332 operation mode SPEED MODE Variable/FIX 20%-100% Variable
34 post-purge POST PURGE
341 time TIME 0-1800 0
342 operation mode SPEED MODE Variable/FIX 20%-100% Variable
35 sensor SENSOR
351 min. pressure RANGE MIN -500-+500 Pa 0
352 max. pressure RANGE MAX 0-1000 Pa 150 Pa
36 parameters PROPERTIES
361 alarm limit draft ALARM LIMIT 100-300%. 300%
362 alarm delay ALARM DELAY 0-120 s. 15 s.
363 min. voltage SPEED MIN 0-MENU 364 10%
364 max. voltage SPEED MAX MENU363-100% 100%
365 xp INTAKE Xp 0-30 15
366 ti INTAKE Ti 0-30 8
367 pressure type PRESSURE MOD (+) or (-) Negative
4 display DISPLAY
41 language LANGUAGE Eng/Fr./Sp. English
42 units UNIT Pa/inWC inWC
43 display lights LIGHT ON/OFF ON
5 alarm
51 alarm status ERROR
52 alarm log ERROR LOG
53 reset RESET MAN/AUT AUT
6 service SERVICE
61 version no. VERSION
62 i/o I/O-VIEW
621 burner i/o* AUX OUT XXX XXX
622 relay board* RELAY OUT XXXX
623 exhaust i/o* EXH XTP x.xV OFF
624 INTAKE I/O* INT XTP x.xV OFF
625 TRIAC BOARD TRIAC BOARD
626 DRAFT INPUT DRAFT INPUT
627 Override input OVERRIDE IN
628 Alarm Relay ALARM OUTPUT
629 Application APPLICATION
63 Triac board TRIAC BOARD INTAKE/ EXHAUST
64 OVERRIDE OVERRIDE
641 Draft Mode EXHAUST OFF/NORMAL/MAX MAX
642 Intake Mode INTAKE OFF/NORMAL/MAX NORMAL
643 Alarm Mode ALARM MODE ON/OFF OFF
65 OPTIONS OPTION
651 Prioritized Duty PRIORITY ON/OFF OFF
652 Bearing Activation BEARING CYCLE ON/OFF ON
653 Allow Prime ALLOW PRIME 1-250 S/OFF OFF
65 FACTORY RESET FACTORY YES/NO NO
