Table: Charger_Alarms
NO.
Alarm_ID
Alarm_Name
Alarm_Level
Description
Remark
1
1
System Not
Availabe
CA
System is out of service
and charge is not allowed.
This usually comes after
other critical alarm(e,g
EPO pressed)
2
2
System Diabled
MA
System is out of service
and charge is not allowed.
This happens after system
is set to 'In-operative' by
service guy or backend.
3
3
All CCU Comm
Fail(Not used right
now)
CA
Note used any longer
4
4
Server Comm Fail
MA
Whether the network is not
accessable or the
connection between server
and charger is broken
5
5
All kWhMeter Not
Installed
MA
All kWh meters are set to
'Not installed'. This means
system not available
6
6
CCU Comm Fail
CA
The communication
between IMMU2 and
IMSU-D is failed.This
means system not
available
7
7
EPO is pressed
CA
This means system not
available
8
8
Door is opened
CA
This means system not
available
9
9
SPD alarm
CA
This means system not
available
10
10
Mains Fail Alarm
CA
This means system not
available
11
11
Gun is disabled
MA
The specified gun is out of
service and not allowed to
charge.This happens after
the gun is set to 'In-
operative' by service guy
or backend.
Gun A/B/C shall be
specified
12
12
System over temp
MA
The temperature
measurement from sensor
is over the high limit
point(default is 75 'C)
Note that this alarm
does not stop/prohibit
charge function
13
13
All Rectifier Failure
CA
This means system not
available
14
14
All Rectifier Comm
Fail
CA
This means system not
available
15
15
Rectifiers Failure
CA
This means the specified
gun will not be available
Rectifier group 1/2
shall be specified
16
16
Rectifiers Comm
Fail
CA
This means the specified
gun will not be available
Rectifier group 1/2 be
specified
17
17
Insulation Comm
Fail
CA
This means the specified
gun will not be available
18
18
Output Shorted
CA
This is from Rectifiers after
detected the internal circuit
shorted
