EXP EXP180K2-FD - 2 General Characteristics; 2.1 Technical Characteristics; 2.2 Model Description

2 GENERAL CHARACTERISTIC
2.1Technical characteristics
EXP180K2-HD technical characteristics are indicated in the Table 1.
This system has two DC output connection (CCS2).
Table 1 Technical Characteristics
Technical Data
Description
Remarks
Nominal Input
Phases/Lines
3 phases + neutral + PE
Voltage
380/400 Vac (+/-10%)
Frequency
50 Hz/ 60Hz
Current
Max 288A
Power
180kW
Power factor
≥0.99
System Efficiency
≥ 94.5% (Full load and rated input and output)
DC Output
CCS2
Voltage
150~1000Vdc
Current
200A (limited by the gun capacity)
Nominal Power
180kW
Cabinet
Dimensions(W*D*H)
700*750*1750
（
mm
）
Weight
290 kg (excluding power module, power module is 21kg/pcs)
Protection Degree
IP55
，
IK10
HMI and
Command Unit
Local interface
TFT Color touch display 7”
Communication
Router 3G/4G (GSM, CDMA or LTE)
Protocol
OCPP1.6 J specification
Environment
conditions
Operating temperature
1
-25°C~+50°C
Transportation/storage
temperature
-40°C~+70°C
humidity
5%RH~95%RH
Place of installation
Outdoor
2
Altitude
2000m
Sound Noise
≤65dB (nominal input/output power, the environment
temperature is 25°C.)
Atmospheric pressure
80KPa~110KPa
Overvoltage category
II
Protection class
Class I
Note 1: The DC Charger provides full output power up to 45°C, output power derating 5% / °C above 45°C.
Note 2: The protection level of the DC Charger is IP55. But for charging safety it should not be used during rain or snow if water
can reach the charger connector.
Specifications are subject to change, without prior notice.
2.2 Model description
Model
Configuration
Remarks
EXP180K2-FD-EU
CCS-2 + CCS-2
180KW
