19
Elen
INSTALLATION
The porta-filter sets
Filter basket locking spring
Filter basket
Porta-filter spring slot
Porta-filter & filter basket
for double espresso (14g)
Porta-filter and filter basket
for single espresso (7g)
Correct
position.
Porta-filter not
fully inserted.
Group gasket is
worn out, please
replace.
Align the porta-filter's two flanges with
the two slots in the group housing.
Insert the porta-filter and rotate it counterclockwise
until the handle is approximately perpendicular to the
face of the coffee machine.
(+/- 5 degrees)
Porta-filter
Inserting the porta-filter into the group
