METER DESCRIPTION
Front panel
1. Current Sense Jaws
2. Function switch
3. Keypad
4. LCD display
5. Input jacks
Note: The tilt stand and battery compartment door are
located on the rear of the meter.
Symbols
AC current or Voltage
DC current or Voltage
Continuity
H Display hold
REL Relative
AUTO Auto range
Diode
Display Backlight
Units
mV, V millivolt, volt (voltage)
Ω, kΩ, MΩ ohm, kilohm, megohm (resistance)
% percent (duty cycle)
μA, mA, A microamps, milliamps, amps (current)
Hz, kHz hertz, kilohertz (frequency)
nF, μF nanofarad, microfarad (capacitance)
