380926 4.1 07/07
8
SPECIFICATIONS
Function Range Resolution Accuracy Remarks
400.0A 0.1A ±(2.0% + 5d) AC/DC Current
(Clamp on)
2000A 1A ±(2.0% + 8d)
45Hz to 1KHz
4.000V 1mV
40.00V 10mV
400.0V 0.1V
AC Voltage
True RMS
1000V 1V
±(1.2% + 5d) 45Hz to 1KHz
Input Impedance:
10Mohms
400.0mV 0.1mV ±(0.5% + 2d)
4.000V 1mV
40.00V 10mV
400.0V 0.1V
DC Voltage
1000V 1V
±(1.0% + 2d)
Input Impedance:
10Mohms
400.0 Ω 0.1Ω
4.000 kΩ 1Ω
40.00 kΩ 10Ω
400.0 kΩ 100Ω
±(1.0% + 5d)
4.000 MΩ 1kΩ
±(2.0% + 2d)
Resistance
40.00 MΩ 10kΩ
±(3.5% + 5d)
400.0µA 0.1µA
4000µA 1µA
40.00mA 0.01mA
AC/DC Current
(Direct Input)
400.0mA 0.1mA
±(1.2% + 5d) 45Hz to 1KHz
5Hz 0.001Hz
50Hz 0.01Hz
500Hz 0.1Hz
5kHz 1Hz
50kHz 10Hz
Frequency
100kHz 100Hz
±(1% + 5d)
50nF 10pF
500nF 100pF
5µF 0.001µF
Capacitance
50µF 0.01µF
±(3% + 5d) Accuracy stated
after a relative "REL"
zero performed
Duty Cycle 1 to 99% 0.1% ±(1% + 5d)
Continuity Audible tone; <10 ohms approximately
Open circuit voltage; 0.5V approximately
Conductor Size 60mm (2.36”) maximum
Measurement parameters ACA, DCA, ACV, DCV, Resistance, Diode, Frequency,
Capacitance, Duty Cycle, Continuity
Current Sensor Hall Effect
Zero adjust Automatic except for DCA (Push-button)
Diode Test Test current of 0.6mA typical;
Open circuit voltage <1.6V DC typical.
Battery type 9V NEDA 1604
Range Selection Auto or manual
Display 0.6” (15mm) 5000 Count Backlit LCD
Overload Indication "OL"
Power Consumption 5mA approx.
Low Battery Indication Battery icon appears on LCD
Sampling rate 1 reading every 0.35 seconds approx.
Standards CE, IEC 1010-1 CAT IV 600V
Operating Temperature/Humidity 32 to 122
o
F (0
o
C to 50
o
C) / <80%
Dimensions 10 x 2.9 x 1.5” (255 x 73 x 38mm)
Weight 0.85 lbs. (380g)
