EX65x‐en‐GB_V1.6 7/16
24
CapacitanceMeasurementNotes:
The display will show “OL” if a capacitor is short‐circuited or if the measured capacitance >
maximum range of the instrument.
The bargraph is not active in the capacitance measurement mode.
Capacitance measurements > 600μF may require several seconds to obtain a stable
reading.
In order to ensure measurement accuracy, discharge residual charges before measuring
capacitance; Use maximum safety when working with high voltage capacitors to prevent
damage to the instrument and risk to personal safety.
Disconnect test leads and circuit under test after measurements are completed.
