CapacitanceMeasurements
WARNING:Toavoidelectricshock,removepowertothecircuitundertestanddischarge
thecapacitorundertestbeforemeasuring.Donottestoncircuitsordeviceswhere60VDCor
30VACispresent.
1. Setthefunctionswitchtothe capacitanceposition.
2. InserttheblacktestleadbananaplugintothenegativeCOMjack
andtheredtestleadbananaplugintothepositive
jack.
3. PresstheMbuttontoselecttheunitofmeasuresymbolF.
4. Touchthetestprobetipsacrossthepartundertest.
5. UsetheRelativemode
tocomparemeasurementstoasaved,knowncapacitancevalue.
SeethededicatedRelativemodeinstructionsinthisuserguideformoredetail.
6. Readthecapacitancevalueinthedisplay(bargraphisnotavailableincapacitancemode).
7. Thedisplaywillindicatetheproperdecimalpointandvalue.
Relative

Fig4‐8CAPACITANCEMEASUREMENTS




