Extech Instruments EX655 User Manual

EX65x‐en‐GB_V1.67/16
5
SafetySymbolsthataretypicallymarkedonmetersandinstructions

Thissymbol,adjacenttoanothersymbol,indicatestheusermustrefertothe
manualoruserguideforfurtherinformation.

Riskofelectricalshock

Fusesymbol

Equipmentprotectedbydoubleorreinforcedinsulation

LowBatterysymbol

ConformstoEUdirectives

Donotdiscardthisproductinhouseholdtrash.

ACmeasurement
DCmeasurement

Earthground

UnsafeVoltageAlert
Whenthemeterdetectsavoltageequaltoorgreaterthan30Voravoltageoverload(OL)inVorLoZmode,
thesymbol
isdisplayed.Thissystemwasdesignedtoalerttheuserofapotentiallyhazardousvoltage.
PERIEC1010OVERVOLTAGEINSTALLATIONCATEGORY
OVERVOLTAGECATEGORYI
EquipmentofOVERVOLTAGECATEGORYIisequipmentforconnectiontocircuitsinwhichmeasuresare
takentolimitthetransientover‐voltagestoanappropriatelowlevel.
Note–Examplesincludeprotectedelectroniccircuits.
OVERVOLTAGECATEGORYII
EquipmentofOVERVOLTAGECATEGORYIIisenergy‐consumingequipmentto
besuppliedfromthefixed
installation.
Note–Examplesincludehousehold,office,andlaboratoryappliances.
OVERVOLTAGECATEGORYIII
EquipmentofOVERVOLTAGECATEGORYIIIisequipmentinfixedinstallations.
Note–Examplesincludeswitchesinthefixedinstallationandsomeequipmentforindustrialusewith
permanentconnectiontothefixedinstallation.
OVERVOLTAGECATEGORYIV
EquipmentofOVERVOLTAGECATEGORYIVisforuseattheoriginoftheinstallation.
Note–Examplesincludeelectricitymetersandprimaryover‐currentprotectionequipment
