Air Velocity Specifications
Air Velocity Range Resolution Accuracy
m/s (meter per second)
1to80.00
0.01
ft/min (feet per minute)
200to15733
1
km/h (kilometers per hr)
3.5to288.0
0.1
MPH (miles per hour)
2.25to178.66
0.01
Knots (nautical mph)
2.0to154.6
0.1
±(1%FS + 5digits)
@ 5.00 to 10.00m/s
Air Flow Specifications
Air Flow Range Resolution
CFM (cubic feet per minute) 0 to 99.999ft
3
/min 0.0001 to 100
CMM (cubic meters per minute) 0 to 99.999m
3
/min 0.001 to 100
Manometer Specifications
Accuracy ±0.3% F.S. (Full Scale) at 25
o
C
Repeatability ±0.2% (Max ± 0.5% F.S.)
Linearity/Hysteresis ±0.29% F.S.
Pressure Range
±5000 Pa
Maximum Pressure 10psi
Response Time 0.5 Seconds typical
Range Indicator Over range: Err.1; Under range: Err.2
Units Range Resolution
PSI 0.7252 0.0001
mbar 50.00 0.01
inH2O 20.07 0.01
mmH2O 509.8 0.1
Pa 5000 1
Temperature Specifications
Temperature Range Resolution Accuracy
o
C 0 to 50.0
o
C 0.1 ±1.5
o
C
o
F 32.0 to 122.0
o
F 0.1 ±3.0
o
F
