LANPlug 2000 LED Status Overview
Performance
• Blinking Red: Powerline throughput is less than 100Mbps.
• Blinking Amber: Powerline throughput is greater than 100Mbps,
but less than 200Mbps.
• Blinking Green: Powerline throughput is greater than 200Mbps.
• Solid Amber: Adapter is ON but not paired with any other
adapters.
• Blinking Amber: Adapter is in Powerline pairing mode.
• Solid Green: Adapter is paired with another Powerline adapter
and is active.
• Solid Green: Ethernet link is up.
• OFF: No Ethernet connectivity.
• Powerline Pairing: Pressing the pairing button between 3 to 5
seconds (amber Powerline LED starts blinking), the pairing
process starts.
• Factory Reset: Press the pairing button and hold approximately
20 seconds until the Powerline and Ethernet LEDs turn on. The
powerline LED turns amber once the process is completed.
Boot - Up
• During the boot up process, the Powerline LED will be green and
then turn amber once the process is completed, approximately
20 seconds.
