Una LED Status Overview
• Solid Amber: Adapter is ON but not paired with any other adapters.
• Blinking Amber: Adapter is in Powerline pairing mode.
• Solid Green: Adapter is paired with another Powerline adapter and
is active.
• Fast blinking Green: Adapter is trying to connect to another
adapter.
• Slow blinking Green: Adapter is connected to the Powerline
network.
• Solid Green: Ethernet link is up.
• OFF: No Ethernet connectivity.
• Solid Amber: Default SSID is broadcasted (“Guide_xxxxxxxx”).
• Solid Green: Specified SSID is broadcasted.
• OFF: No SSID is broadcasted.
• Powerline Pairing: Pressing the pairing button between 3 to 5
seconds (amber Powerline LED starts blinking), the pairing process
starts.
• Factory Reset: Press the pairing button and hold approximately 20
seconds until the Powerline and Wi-Fi LEDs turn on. The Powerline
and Wi-Fi LED’s turn amber once the process is completed.
Boot - Up
• During the boot up process after a factory reset, all LED’s will be
green and then the Powerline and Wi-Fi LED’s turn amber once the
process is completed, approximately 90 seconds.
